The Tritonbuoys TM2400 is a highly durable, high-visibility navigational aid suitable for various applications, such as lateral marking, special marking, and cardinal marking. Its internal steel components are made from stainless steel, enhancing both its longevity and strength. The TM2400 is constructed in multiple segments to allow for easy transportation, assembly, servicing and partial replacements where necessary.
| General Characteristics | |
| Diameter | 2400 mm |
| Focal Plane Height | 3455 mm + Navigation Lantern |
| Available Colour | Green, Red, Yellow, White as per IALA recommendations; Customisation Available. |
| Total Float Volume | 6685 L |
| Nominal Freeboard | 1350 mm |
| Nominal Draft | 750 mm |
| Total Reserve Buoyancy | 5225 kg |
| Operational Buoyancy | 2325 kg |
| Maximum Mooring Load | 2325 kg |
| Draft, Maximum | 1250 mm |
| Freeboard, Minimum | 850 mm |
| Visual/Focal Area | 4.94 m^2 |
| Physical Characteristics | |
| Material | Rotationally- Moulded UV Stabilized Virgin Polyethylene |
| Wall Thickness | 14 mm Buoy Section; 7 mm Top Section |
| Ballast (Internal Concrete) | 1000 kg (Customisable) |
| Filling | Closed cell Polyurethane (Density > 45kg/m^3) |
| Total Height | 4200 mm |
| Width | 2400 mm |
| Mass | 1800 kg (including internal ballast) |
| Certifications | |
| IALA | Surface colours compliant to IALA E-108 |
| Quality Assurance | ISO9001:2015 |
| Warranty | 3 Years** |
| IP/Trademark | 'TRITONBUOYS® is a registered trademark |
| Options Available | |
| Marine Lanterns | |
| Customised Configuration | |
| Day Marks | |
| Internal Radar Reflector | |
| Battery Box | |
|
* Specifications subject to change or variation without notice ** Warranty subject to terms & conditions |
|
